Test method: In the portable power banks battery input 3.4 power supply, observe the prompt of the portable power banks LED and the portable power banks supply to the low power shutdown output;

    function test:

    High efficiency battery online detection battery X-ray detection - battery X-ray detection.

Battery X-ray detection is widely used in the battery industry inside the internal defect and effect analysis of the battery. Get the battery X-ray detection

    According to the requirements of the design input, it is not the same as the key to the design input, and the power requirements are different. Please formulate it yourself;

    Output ripple voltage standard: less than 200MV test method: Select the AC test file with an oscilloscope to see if the ripple voltage is in line; Touch screen can not fail

    Stand-up current: Standard: Standhable current is generally micro-level: HR61: Designing less than 300UA test method: connected to a current table in the battery, enter the battery terminal of the portable power banks; observe the portable power banks supply, when the power is not worked, 1 When you enter the sleep state within minutes, it will be less than 300ua;

    Contents that must be tested in production: 

    1, battery display:   

    needs to have a reference voltage input to the mobile power supply to see if the corresponding LED is on;  

    2, all LEDs can be bright  

    3, charging current: see if there is charging current and charging Indication;

    4, load voltage: to see whether the load voltage meets  

    5, light-load protection: 2 values need to be tested:

    A: whether it will shut down if the current is less than the light-load   

    B: will shut down if the current is greater than the light-load
